Name: Proline Promass U 500 Coriolis flowmeter
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: Proline Promass U 500
Price: 2,540.00 USD
Availability: InStock

Thuis > producten > Elektromagnetische Stroommeter >

Proline Promass U 500 Coriolis flowmeter

Proline Promass U 500 flowmeter

Coriolis flowmeter with warranty

Electromagnetic flow meter industrial

Plaats van herkomst:

Zwitserland

Merknaam:

Endress+Hauser

Certificering:

Modelnummer:

Proline Promass U 500

Neem contact met ons op

Vraag een offerte

Proline Promass U 500 Coriolis flowmeter

Productgegevens

Bevochtigde materialen:

Meetbuizen: RVS 1.4435, 316L

Gemeten variabelen:

Massa, dichtheid, temperatuur

Max. metingsfout:

Massastroom (vloeistof): ±0,5%

Meetbereik:

0 tot 75 kg/u (0 tot 165,3 lb/min)

Max. verwerkingsdruk:

6 bar (87 psi)

Markeren:

Proline Promass U 500 flowmeter

Coriolis flowmeter with warranty

Electromagnetic flow meter industrial

Betaling en verzendvoorwaarden

Min. bestelaantal

1 stks

Verpakking Details

Elke eenheid heeft een individuele doos en alle dozen zijn verpakt in standaardpakketten of beschikb

Levertijd

5-8 WERKDAGEN

Betalingscondities

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Levering vermogen

1000 stuk/stukken per week bespreekbaar

Verwante producten

Proline Promass S 300 Coriolis flowmeter

Vind de beste prijs

Proline Promass P 500 Coriolis flowmeter

Vind de beste prijs

Proline Promass Q 300 Coriolis flowmeter

Vind de beste prijs

Proline t-mass F 500 thermal mass flowmeter

Vind de beste prijs

Neem contact met ons op

Contact opnemen

Productbeschrijving

Proline Promass U 500 Coriolis Flowmeter

The Proline Promass U 500 is a precision single-use Coriolis flowmeter specifically engineered for biopharmaceutical applications in the life sciences industry.

Field of Application

Designed for the transition from multi-use to single-use devices and batch to continuous manufacturing, the Promass U 500 delivers multivariable measurement with enhanced reliability, high accuracy, and cGMP compliance. Ideal for upstream and downstream applications in monoclonal antibodies (mAb) processes.

Key Benefits

Best-in-class measuring accuracy with Coriolis multivariable technology
Highest turndown ratio - one sensor accommodates all disposable line sizes
cGMP compliance with required documentation and attributes
Simple one-hand mounting and automated calibration data transfer
Self-drainability and air bubble escape through optimized mounting angles
No field calibration required with integrated Heartbeat Technology
Digital integration with modern single pair Ethernet communication protocols

Technical Specifications

Measuring Principle	Coriolis
Nominal Diameter Range	¹⁄₈" to 1"
Measured Variables	Mass, density, temperature
Max. Measurement Error (Mass Flow)	±0.5%
Measuring Range	0 to 75 kg/h (0 to 165.3 lb/min)
Max. Process Pressure	6 bar (87 psi)
Medium Temperature Range	3 to 60°C (37.4 to 140°F)
Ambient Temperature Range	5 to 40°C (41 to 104°F)
Wetted Materials	Measuring tubes: Stainless steel 1.4435, 316L Hose connection nipple: Makrolon Rx 1805 polycarbonate

Sensor Features

One sensor fits all DN sizes with four disposable line sizes
One-hand mounting with intuitive clamping mechanism
Optimized mounting angles for self-drainability and air bubble escape
Disposable components made of 1.4435 (316L) and polycarbonate
Fully traceable cGMP compliance

Transmitter Features

Comprehensive process and diagnostic information access
Freely configurable I/O functionality
Integrated verification with Heartbeat Technology
Remote version with up to 4 I/Os
Backlit display with touch control and WLAN access
Standard cable connection between sensor and transmitter

Electrical Specifications

Display/Operation	4-line backlit display with touch control Configuration via local display and operating tools
Outputs	4-20 mA HART (active/passive) 4-20 mA WirelessHART 4-20 mA (active/passive) Pulse/frequency/switch output (active/passive) Double pulse output (active/passive) Relay output
Inputs	Status input, 4-20 mA input
Digital Communication	Modbus RS485, PROFINET over Ethernet-APL
Power Supply	AC 100 to 230 V / DC 24 V (non-hazardous area)

Certifications & Approvals

Product Safety: CE, C-tick, EAC marking
Functional Safety: IEC 61508 compliant, applicable per IEC 61511
Hygienic Approvals: cGMP compliance, ASME BPE, BPOG, FDA

Degree of Protection: Transmitter IP66/67, Type 4X enclosure; Sensor IP54
